NPT Threaded Pipe Cap Forged Stainless Steel 3000 High Pressure Fitting | Select Size and SS Type
$0.00
In stock
SKU
NPT-CAP-HP
-
Select Size and SS Type Above
-
Forged Stainless Steel
-
NPT Female Threaded Cap
-
High Pressure Class 3000# Pipe Fitting
-
Max Pressure: 3000 PSI
-
MFG Standards: ASME ASTM
-
Top Quality Import
3000# Cap Specs
| Pipe Thread Size | Thread Diameter | Outside Diameter | Total Length |
| 1/8" NPT | 0.405" | 0.62" | 0.75" |
| 1/4" NPT | 0.540" | 0.75 | 1.0" |
| 3/8" NPT | 0.675" | 0.88 | 1.0" |
| 1/2" NPT | 0.840" | 1.12" | 1.25" |
| 3/4" NPT | 1.050" | 1.38" | 1.44" |
| 1" NPT | 1.315" | 1.75" | 1.62" |
| 1-1/4" NPT | 1.66" | 2.25" | 1.75" |
| 1-1/2" NPT | 1.90" | 2.50" | 1.75" |
| 2" NPT | 2.375" | 3.0" | 1.88" |
| 2-1/2" NPT | 2.875" | 3.62" | 2.38" |
| 3" NPT | 3.5" | 4.25" | 2.56" |
